Structure |
Portable, desktop easy to use |
Screen |
4x20 character LCD display |
Menu |
English |
Mode of Operation |
Normobaric infusion technique The patient is not connected to the device during treatment |
Concentration Range |
Reliable precise dosing 0 - 1 µg / ml 0.1 µg / ml 1 - 80 µg / ml 1 µg / ml |
Photometric Measurement |
Continuous ozone measurement with automatic calibration is displayed on the digital display. |
Volume Flow |
8.2 lt / min depending on the concentration range |
Working Pressure Inside the Device |
2.6 bar |
Catalyst |
Catalyst that converts unused ozone gas into oxygen after the process |
Absorbent |
Powerful vacuum motor, 0.5 ml / min |
Vacuum Value |
780 mbar |
Medical Ozone Inlet Pressure |
1 - 10 bar |
Applicable Treatments |
Major autohemotherapy Minor autohemotherapy Local injections Bag therapy Rectal insufflation Ozonated water Serum physiological |
Dimensions |
150 x 438 x 275 mm |
Weight |
6,36 kg |
Electrical Data |
200-240 V AC 50Hz-60Hz 50 WATT |
Input Voltage |
100-240 V |
Operating temperature |
10 - 40 °C |
Storage Temperature |
-10 - 60 °C |
Optimum Ozone Temperature |
22 - 27 °C |
Working Humidity |
% 35 - 80 RH |
Certifications |
CE 1984 ISO 13485:2016 |
Warranty |
2 years |
